Grundfos CMB-SP 1-36 Pump With PM1 Controller

Grundfos CMB-SP 1-36 I-C-A-A-A-A Self-Priming Pump 98507562

The Grundfos CM Booster self-priming pump with PM1 pressure manager is a compact booster solution for water supply in domestic and light commercial applications. The pressure booster unit consists of a Grundfos CM self-priming pump and a Grundfos PM1 pressure manager. The pressure manager allows the pump to start and stop automatically according to demand and protects the pump from dry running. The CM Booster self-priming pump can create a suction lift of up to 8 m, and it is very easy to install. When the booster has been connected to the pipework, just plug it into a socket, and the system is operational.

Features

• compact
• easy installation
• self-priming up to 8 m
• automatic resetting of alarms
• dry-running protection
• anti-cycling (leakage detection)
• maximum continuous operating time.

Suitable for

Commercial water pressure boosting

Domestic water pressure boosting

Motor / power: 500W
Max. flow: 25LT/min
Head: 36m
Inlet: 1″F / 25mm
Outlet: 1″M / 25mm
Pressure: 360kPa
Body: 304 Stainless Steel
Diffuser: Technopolymer
Impeller:304 Stainless Steel
Pump Shaft: 304 Stainless Steel
Mechanical Seal : Carbon with resin/ceramic
Start pressure: PM1 – 1.5 bar
Warranty on pump: 2 Years
Code: 98507562
