CMBE 5-62

Grundfos CMBE 5-62 I-U-C-A-D-B Variable Speed Constant Pressure Pump 98374712

The Grundfos CME Booster is a compact booster system designed to provide reliable water supply for domestic applications. Its built-in speed controller maintains constant water pressure throughout the pipe system. When water usage changes, a pressure sensor detects the variation and signals the controller to automatically adjust the motor speed, ensuring the system performs efficiently.

Installation is quick and straightforward. Once the pipework is connected, simply plug the unit into a power outlet and the system is ready to operate.

The CME Booster consists of:

• CME pump with integrated frequency converter
• 5-way valve
• expansion tank
• pressure gauge
• User friendly interface The user-friendly interface features LED indicators showing operational status and buttons for pressure adjustment.

Features

• Constant pressure, integrated speed control
• compact
• robust, stainless steel
• easy installation
• dry run protection

Constant pressure via integrated speed control
• Compact construction
• Robust, stainless steel parts
• Easy installation and user-friendly control panel
• Dry-running and thermal protection
• Low noise level, 55 dB(A)

• Reduced pump start/stops

• Low energy consumption with efficient Grundfos MGE motor IE5

Thermal protection CME Booster pumps require no external motor protection. The MGE motor incorporates thermal protection against slow overloading and blocking. Grundfos CMBE Booster is mainly used for domestic and light commercial water supply or booster systems. CMBE is Suitable for covered installation.

NB: Max. 1 m, including suction-pipe pressure loss at a liquid temperature of +20 °C. (not self-priming)

Motor / power: 1500W
Max. flow: 125LT/min
Head: 68m
Inlet: 1¼″F / 32mm
Outlet: 1″F / 25mm
Pressure: 680kPa
Body: 304 Stainless Steel
Diffuser: Technopolymer
Impeller: 304 Stainless Steel
Pump Shaft: 304 Stainless Steel
Mechanical Seal : Carbon with resin/ceramic
Start pressure: Integrated Frequency converter
Tank Volume: 2LT

Liquid temperature: 0°C to +60°C
Ambient temperature: 0°C to +55°C
Supply voltage: 1 x 240 Volt 50 Hz
System pressure: Factory Setting 6 bar
Enclosure class: Suitable for covered installation (IP55)

Note: Pressure setting available on pump control panel. Further adjustments via Grundfos GO App

Warranty on pump: 2 Years
MPN: 98374712
